Brushless AC Drives with Fieldbus Integration



Code

Power supply voltage

Rated current
[A]

Peak current
[A]

Control mode

Digital
inputs

Digital
outputs

Feedback
interface

Mounting

[Vac]

[Vdc]

Min

Max

Min

Max
AW5D3560_4T2-30d0_80  24807.110.0Multiprotocol: ProfiNet - EtherCAT - EtherNET/IP - PowerLink - Modbus TCP/IP84isolated incremental encoder input 5V differential RS422 or single-ended TTL/CMOSWall mounting
AW5D3560_4T2-34d0_80  24807.110.0Multiprotocol: ProfiNet - EtherCAT - EtherNET/IP - PowerLink - Modbus TCP/IP84isolated Hall sensor 5V single-ended (TTL/CMOS) input or Resolver input Wall mounting
AW5D3560_4T2-35d0_80  24807.110.0Multiprotocol: ProfiNet - EtherCAT - EtherNET/IP - PowerLink - Modbus TCP/IP84isolated multiturn absolute encoder 5V Endat2.2, BiSS-C or SSI inputWall mounting
AW5A91K5L221-30a038085265  5.212.0CANbus (Canopen DS402) or Modbus RTU43incremental encoder input 5V differential RS422 or single-ended TTL/CMOS | incremental encoder output 5V differential RS422 | absolute encoder input 5V BISS-C or SSI interface | Hall sensor signals input 5V single-ended TTL/CMOSWall mounting
AW5A91K5L2E1-30a038085265  5.212.0CANbus (Canopen DS402) or Modbus RTU43incremental encoder input 5V differential RS422 or single-ended TTL/CMOS | incremental encoder output 5V differential RS422 | absolute encoder input 5V BISS-C or SSI interface | Hall sensor signals input 5V single-ended TTL/CMOSWall mounting
AW5A91K5L2G1-30a038085265  5.212.0CANbus (Canopen DS402) or Modbus RTU1612incremental encoder input 5V differential RS422 or single-ended TTL/CMOS | incremental encoder output 5V differential RS422 | absolute encoder input 5V BISS-C or SSI interface | Hall sensor signals input 5V single-ended TTL/CMOSWall mounting
AW5A91K5H221-30a068085265  5.212.0EtherCAT (CoE)43incremental encoder input 5V differential RS422 or single-ended TTL/CMOS | incremental encoder output 5V differential RS422 | absolute encoder input 5V BISS-C or SSI interface | Hall sensor signals input 5V single-ended TTL/CMOSWall mounting
AW5A91K5T221-30a098185265  5.212.0ProfiNET (PROFIdrive)43incremental encoder input 5V differential RS422 or single-ended TTL/CMOS | incremental encoder output 5V differential RS422 | absolute encoder input 5V BISS-C or SSI interface | Hall sensor signals input 5V single-ended TTL/CMOSWall mounting
AW5A6750L221-20a0380100120  3.012.\0CANbus and Modbus-RTU43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A6750L2G1-20a0380100120  3.012.0CANbus and Modbus-RTU1612isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A6750H221-20a0680100120  3.012.0EtherCAT43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A6750T221-20a0981100120  3.012.0ProfiNET (PROFIdrive)43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A9750L221-20a0380100240  3.012.0CANbus and Modbus-RTU43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A9750T221-20a0981100240  3.012.0ProfiNET (PROFIdrive)43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A9750L2G1-20a0380100240  3.012.0CANbus and Modbus-RTU1612isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting
AW5A9750H221-20a0680100240  3.012.0EtherCAT43isolated input for incremental encoder 5V differential RS422 or single-ended TTL/CMOS or for absolute encoder 5 V with BiSS-C or SSI interfaceWall mounting

Brushless AC Control on Fieldbus

The Vanadio fieldbus drives from Ever Motion Solutions are vector‑controlled devices designed for the control of brushless AC motors in advanced industrial applications. Fully digital and based on ARM Core M4 technology, they are available with major industrial fieldbus systems such as EtherCAT, PROFINET, CANopen, Modbus TCP/IP, Modbus RTU, and Powerlink, enabling easy integration into the most widely used automation architectures.


Precision, Safety, and Operational Reliability

The Vanadio series enables closed‑loop motor control with feedback from incremental or absolute encoders, both single‑turn and multi‑turn, ensuring high precision and stable operation. The drives are equipped with Safe Torque Off (STO) safety functionality and UL certification, making them suitable for industrial applications that require reliability, continuous operation, and functional safety.
