 | MT11HE20015E401 | NEMA 11 - 28 mm square | 170.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 51.80 | Double shaft with encoder mounted | 20 | IP40 |
 | MT08HE11004M40V | NEMA 8 - 20 mm square | 15.00 | 1.80 | 5 | 40.00 | 4 wires for bipolar connection | 27.80 | Single shaft | 2 | IP40 |
 | MT17HE18018E4L1 | NEMA 17 - 42 mm square | 480.00 | 1.80 | 5 | 180.00 | 4 wires for bipolar connection | 47.70 | Double shaft with encoder mounted | 80 | IP65 |
 | MT10HE10007M40C | NEMA 10 - 25 mm square | 33.00 | 1.80 | 5 | 70.00 | 4 wires for bipolar connection | 23.50 | Single shaft | 2 | IP20 |
 | MT11HE12010B401 | NEMA 11 - 28 mm square | 70.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 30.10 | Single shaft | 9 | IP40 |
 | MT11HE10007M4LC | NEMA 11 - 28 mm square | 71.00 | 1.80 | 5 | 67.00 | 4 pins for bipolar connection | 24.20 | Single shaft | 9 | IP65 |
 | MT17HE18020B4E1 | NEMA 17 - 42 mm square | 520.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 47.70 | Double shaft with encoder mounted | 82 | IP30 |
 | MT17HE18017B4F1 | NEMA 17 - 42 mm square | 450.00 | 1.80 | 5 | 170.00 | 4 wires for bipolar connection | 43.70 | Double shaft with brake mounted | 69 | IP20 |
 | MT17HE19020E403 | NEMA 17 - 42 mm square | 480.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 48.10 | Double shaft with encoder mounted | 77 | IP40 |
 | MT11HE20010M400 | NEMA 11 - 28 mm square | 140.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 50.40 | Single shaft | 20 | IP40 |
 | MT17HE24018E4LC | NEMA 17 - 42 mm square | 720.00 | 1.80 | 5 | 180.00 | 4 wires for bipolar connection | 51.00 | Double shaft with encoder mounted | 115 | IP40 |
 | MT12HE12007M4 | NEMA 12 - 28 mm square | 60.00 | 1.80 | 5 | 67.00 | 4 wires for bipolar connection | 30.10 | Single shaft | 9 | IP30 |
 | MT17HE24020E401 | NEMA 17 - 42 mm square | 720.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 60.10 | Double shaft with encoder mounted | 110 | IP40 |
 | MT17HE19020H401 | NEMA 17 - 42 mm square | 770.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 48.10 | Double shaft with encoder and brake mounted | 77 | IP50 |
 | MT17HE24028B4E4 | NEMA 17 - 42 mm square | 860.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 59.70 | Double shaft with encoder mounted | 128 | IP30 |
 | MT12HE18015B401 | NEMA 12 - 28 mm square | 130.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 39.20 | Double shaft | 12 | IP30 |
 | MT12HE20007M402 | NEMA 12 - 28 mm square | 150.00 | 1.80 | 5 | 67.00 | 4 wires for bipolar connection | 50.40 | Single shaft | 22 | IP30 |
 | MT14HE15023M401 | NEMA 14 - 35 mm square | 160.00 | 1.80 | 5 | 230.00 | 4 wires for bipolar connection | 36.50 | Single shaft | 20 | IP40 |
 | MT23HE22015B4F1 | NEMA 23 - 56 mm square | 1000.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 53.30 | Double shaft with brake mounted | 290 | IP40 |
 | MT23HE31050F401 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 76.50 | Double shaft with brake mounted | 480 | IP40 |
 | MT23HE22028E4L2 | NEMA 23 - 56 mm square | 1100.00 | 1.80 | 5 | 282.00 | 4 wires for bipolar connection | 53.30 | Double shaft with encoder mounted | 280 | IP65 |
 | MT11HE17007M4LC | NEMA 11 - 28 mm square | 127.00 | 1.80 | 5 | 67.00 | 4 pins for bipolar connection | 43.50 | Single shaft | 18 | IP65 |
 | MT14HE21007M401 | NEMA 14 - 35 mm square | 270.00 | 1.80 | 5 | 70.00 | 4 wires for bipolar connection | 52.90 | Single shaft | 22 | IP40 |
 | MT17HE11013M4Y | NEMA 17 - 42 mm square | 200.00 | 0.90 | 5 | 130.00 | 4 wires for bipolar connection | 29.80 | Single shaft | 22 | IP30 |
 | MT17HE24009M4L1 | NEMA 17 - 42 mm square | 710.00 | 1.80 | 5 | 85.00 | 4 pins for bipolar connection | 85.00 | Single shaft | 115 | IP65 |
 | MT17HE14004M4Y | NEMA 17 - 42 mm square | 230.00 | 0.90 | 5 | 40.00 | 4 wires for bipolar connection | 34.00 | Single shaft | 40 | IP30 |
 | MT23HE31028E4LC | NEMA 23 - 56 mm square | 1950.00 | 1.80 | 5 | 282.00 | 4 wires for bipolar connection | 86.50 | Double shaft with encoder mounted | 520 | IP65 |
 | MT17HE12008M402 | NEMA 17 - 42 mm square | 150.00 | 1.80 | 5 | 80.00 | 4 wires for bipolar connection | 29.20 | Single shaft | 25 | IP30 |
 | MT17HE14008M401 | NEMA 17 - 42 mm square | 140.00 | 1.80 | 5 | 80.00 | 4 wires for bipolar connection | 29.70 | Single shaft | 26 | IP30 |
 | MT17HE24028M4LC | NEMA 17 - 42 mm square | 860.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 51.00 | Single shaft | 115 | IP65 |
 | MT17HE16017M4 | NEMA 17 - 42 mm square | 410.00 | 1.80 | 5 | 168.00 | 4 wires for bipolar connection | 39.70 | Single shaft | 57 | IP20 |
 | MT23HE31050E402 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 76.50 | Double shaft with encoder mounted | 520 | IP40 |
 | MT24HE35050E402 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 86.00 | Double shaft with encoder mounted | 900 | IP40 |
 | MT24HE35040B4F1 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 400.00 | 4 wires for bipolar connection | 85.50 | Double shaft with brake mounted | 900 | IP20 |
 | MT34HE29060E401 | NEMA 34 - 86 mm square | 4200.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 74.00 | Double shaft with encoder mounted | 1900 | IP40 |
 | MT17HE18017M4Y | NEMA 17 - 42 mm square | 440.00 | 0.90 | 5 | 168.00 | 4 wires for bipolar connection | 45.00 | Single shaft | 68 | IP30 |
 | MT17HE18010M4V | NEMA 17 - 42 mm square | 500.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 43.70 | Single shaft | 69 | IP30 |
 | MT23HE17004M6P1 | NEMA 23 - 56 mm square | 520.00 | 1.80 | 5 | 40.00 | 6 wires for unipolar or bipolar series connection | 58.90 | Single shaft | 170 | IP65 |
 | MT34HE38020E4VK | NEMA 34 - 86 mm square | 7000.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 97.30 | Double shaft with encoder mounted | 2700 | IP40 |
 | MT17HE18010M403 | NEMA 17 - 42 mm square | 450.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 43.70 | Single shaft | 69 | IP30 |
 | MT17HE18025M402 | NEMA 17 - 42 mm square | 470.00 | 1.80 | 5 | 250.00 | 4 wires for bipolar connection | 43.70 | Single shaft | 69 | IP30 |
 | MT17HE14004M4G1 | NEMA 17 - 42 mm square | 260.00 | 1.80 | 5 | 40.00 | 4 wires for bipolar connection | 34.00 | Single shaft | 40 | IP30 |
 | MT17HE19013M402 | NEMA 17 - 42 mm square | 530.00 | 1.80 | 5 | 130.00 | 4 wires for bipolar connection | 47.70 | Single shaft | 82 | IP20 |
 | MT17HE24015M4 | NEMA 17 - 42 mm square | 790.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 59.70 | Single shaft | 220 | IP30 |
 | MT08HE12002M4A1 | NEMA 8 - 20 mm square | 15.00 | 1.80 | 5 | 24.00 | 4 wires for bipolar connection | 27.20 | Threaded single shaft | 2 | IP20 |
 | MT11HE18010M4A2 | NEMA 11 - 28 mm square | 1.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 186.00 | Linear screw with slide guide rail | 12 | IP20 |
 | MT17HE24028M4 | NEMA 17 - 42 mm square | 860.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 59.70 | Single shaft | 115 | IP40 |
 | MT17HE24028B4 | NEMA 17 - 42 mm square | 910.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 59.70 | Double shaft | 220 | IP30 |
 | MT23HE22030M4P1 | NEMA 23 - 56 mm square | 1400.00 | 1.80 | 5 | 300.00 | 4 wires for bipolar connection | 69.90 | Single shaft | 280 | IP65 |
 | MT23HE22028M8P | NEMA 23 - 56 mm square | 1400.00 | 1.80 | 5 | 280.00 | 8 wires for bipolar parallel or bipolar series connection | 70.20 | Single shaft | 280 | IP65 |
 | MT23HE22042M4L1 | NEMA 23 - 56 mm square | 1200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 53.30 | Single shaft | 300 | IP65 |
 | MT34HE38060E404 | NEMA 34 - 86 mm square | 7000.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 95.50 | Double shaft with encoder mounted | 2800 | IP40 |
 | MT23HE31050H401 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 76.50 | Single shaft with encoder and brake mounted | 480 | IP40 |
 | MT34HE44060E401 | NEMA 34 - 86 mm square | 8200.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 112.50 | Double shaft with encoder mounted | 3800 | IP40 |
 | MT34HE47060E4L2 | NEMA 34 - 86 mm square | 8500.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 118.50 | Double shaft with encoder mounted | 380 | IP65 |
 | MT17HE14004M4GY | NEMA 17 - 42 mm square | 230.00 | 0.90 | 5 | 40.00 | 4 wires for bipolar connection | 34.00 | Single shaft | 40 | IP30 |
 | MT11HE18010M4A3 | NEMA 11 - 28 mm square | 1.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 205.00 | Linear screw with slide guide rail | 12 | IP20 |
 | MT17HE15010B4A1 | NEMA 17 - 42 mm square | 240.00 | 1.80 | 5 | 100.00 | 4 wires for bipolar connection | 33.70 | Double shaft with thread on front shaft | 38 | IP20 |
 | MT17HE19023M4A1 | NEMA 17 - 42 mm square | 520.00 | 1.80 | 5 | 230.00 | 4 wires for bipolar connection | 47.70 | Double shaft with thread on front shaft | 81 | IP20 |
 | MTER-0008 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 77.30 | Double shaft with encoder mounted | 480 | IP20 |
 | MT23HE17020B4A1 | NEMA 23 - 56 mm square | 740.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 42.30 | Double shaft with thread on front shaft | 170 | IP20 |
 | MT23HE22025B4H1 | NEMA 23 - 56 mm square | 1080.00 | 1.80 | 5 | 250.00 | 4 wires for bipolar connection | 53.10 | Double shaft | 280 | IP20 |
 | MT24HE35050H403 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 86.00 | Double shaft with encoder and brake mounted | 900 | IP40 |
 | MT34HE26068B4F1 | NEMA 34 - 86 mm square | 4100.00 | 1.80 | 5 | 680.00 | 4 wires for bipolar connection | 67.50 | Double shaft with brake munted and protrusion over the brake | 950 | IP20 |
 | MT34HE31042B8F1 | NEMA 34 - 86 mm square | 5940.00 | 1.80 | 5 | 420.00 | 8 wires for bipolar parallel or bipolar series connection | 78.50 | Double shaft with brake mounted | 1400 | IP20 |
 | MT34HE44060H401 | NEMA 34 - 86 mm square | 8200.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 112.50 | Double shaft with encoder and brake mounted | 3800 | IP40 |
 | MT34HE47060B8F1 | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 118.50 | Double shaft with brake mounted | 2500 | IP30 |
 | MT23HE17028M4 | NEMA 23 - 56 mm square | 780.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 41.90 | Single shaft | 170 | IP30 |
 | MT17HE14015M4G1 | NEMA 17 - 42 mm square | 250.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 32.00 | Single shaft | 40 | IP30 |
 | MT17HE17013M4G3 | NEMA 17 - 42 mm square | 400.00 | 1.80 | 5 | 130.00 | 4 wires for bipolar connection | 39.70 | Single shaft | 57 | IP30 |
 | MT23HE22007M8G1 | NEMA 23 - 56 mm square | 1200.00 | 1.80 | 5 | 70.00 | 8 wires for bipolar parallel or bipolar series connection | 54.70 | Single shaft | 275 | IP30 |
 | MT23FK22010M8G3 | NEMA 23 - 56 mm square | 1100.00 | 1.80 | 5 | 100.00 | 8 wires for bipolar parallel or bipolar series connection | 52.90 | Single shaft | 280 | IP30 |
 | MT34HE50040E4VK | NEMA 34 - 86 mm square | 10000.00 | 1.80 | 5 | 400.00 | 4 wires for bipolar connection | 125.50 | Double shaft with encoder mounted | 4000 | IP40 |
 | MTEN-0081 | NEMA 23 - 56 mm square | 2200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 93.50 | Double shaft with encoder mounted | 480 | IP65 |
 | MTEN-0108 | NEMA 24 - 60 mm square | 2700.00 | 1.80 | 5 | 300.00 | 4 pins for bipolar connection | 85.50 | Double shaft with encoder mounted | 810 | IP65 |
 | MTEN-0118 | NEMA 42 - 110 mm square | 30000.00 | 1.80 | 5 | 700.00 | 8 wires for bipolar parallel or bipolar series connection | 229.00 | Double shaft with encoder mounted | 16200 | IP20 |
 | MTEN-0120 | NEMA 34 - 86 mm square | 4800.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 86.00 | Double shaft with encoder mounted | 1400 | IP65 (rear flange not included) |
 | MTEN-0127 | NEMA 34 - 86 mm square | 5000.00 | 1.80 | 5 | 600.00 | 4 pins for bipolar connection | 78.50 | Double shaft with encoder mounted | 1400 | IP65 |
 | MT23HE31042M4LC | NEMA 23 - 56 mm square | 2200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 86.50 | Single shaft | 516.0 | IP65 |
 | MT23HE31042M4P1 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 93.90 | Single shaft | 480 | IP65 |
 | MT23HE31042B4P1 | NEMA 23 - 56 mm square | 2200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 94.20 | Double shaft with encoder fixing holes provision | 480 | IP65 |
 | MT23HE20020M41C | NEMA 23 - 56 mm square | 720.00 | 1.80 | 5 | 200.00 | 4 wires for bipolar connection | 46.50 | Single shaft | 180 | IP40 |
 | MT23HE22020B602 | NEMA 23 - 56 mm square | 1000.00 | 1.80 | 5 | 200.00 | 6 wires for unipolar or bipolar series connection | 53.30 | Double shaft with encoder fixing holes provision | 280 | IP30 |
 | MT23HE22042M403 | NEMA 23 - 56 mm square | 1150.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 56.50 | Single shaft | 280 | IP40 |
 | MT23HE22015M402 | NEMA 23 - 56 mm square | 1000.00 | 1.80 | 5 | 150.00 | 4 wires for bipolar connection | 53.30 | Single shaft | 286 | IP40 |
 | MT23HE22042B401 | NEMA 23 - 56 mm square | 1200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 53.30 | Double shaft with encoder fixing holes provision | 280 | IP30 |
 | MT23HE26030M40C | NEMA 23 - 56 mm square | 1700.00 | 1.80 | 5 | 300.00 | 4 wires for bipolar connection | 65.50 | Single shaft | 516 | IP40 |
 | MT23HE31028B801 | NEMA 23 - 56 mm square | 1830.00 | 1.80 | 5 | 280.00 | 8 wires for bipolar parallel or bipolar series connection | 76.90 | Double shaft with encoder fixing holes provision | 480 | IP30 |
 | MT23HE31030B801 | NEMA 23 - 56 mm square | 2200.00 | 1.80 | 5 | 300.00 | 8 wires for bipolar parallel or bipolar series connection | 77.30 | Double shaft with encoder fixing holes provision | 480 | IP30 |
 | MT23HE31050M401 | NEMA 23 - 56 mm square | 2200.00 | 1.80 | 5 | 500.00 | 4 wires for bipolar connection | 80.50 | Single shaft | 600 | IP40 |
 | MT23HE31056M4 | NEMA 23 - 56 mm square | 1870.00 | 1.80 | 5 | 560.00 | 4 wires for bipolar connection | 77.30 | Single shaft | 480 | IP30 |
 | MT23HE31050B4Y | NEMA 23 - 56 mm square | 1600.00 | 0.90 | 5 | 500.00 | 4 wires for bipolar connection | 77.30 | Double shaft with encoder fixing holes provision | 480 | IP30 |
 | MTEN-0134 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 85.50 | Double shaft | 900 | IP20 |
 | MT23HE31042B4G1 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 77.30 | Double shaft | 480 | IP30 |
 | MTEN-0149 | NEMA 23 - 56 mm square | 1200.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 53.30 | Double shaft with encoder mounted | 280 | IP20 |
 | MT24HE22020M801 | NEMA 24 - 60 mm square | 1600.00 | 1.80 | 5 | 200.00 | 8 wires for bipolar parallel or bipolar series connection | 54.50 | Single shaft | 450 | IP30 |
 | MT24HE22028M402 | NEMA 24 - 60 mm square | 1600.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 54.50 | Single shaft | 450 | IP40 |
 | MT24HE35030M401 | NEMA 24 - 60 mm square | 2700.00 | 1.80 | 5 | 300.00 | 4 wires for bipolar connection | 855.00 | Single shaft | 810 | IP65 |
 | MT34HE31084M4LC | NEMA 34 - 86 mm square | 4500.00 | 1.80 | 5 | 840.00 | 4 wires for bipolar connection | 78.50 | Single shaft | 1400 | IP65 |
 | MT24HE22030B401 | NEMA 24 - 60 mm square | 1300.00 | 1.80 | 5 | 300.00 | 4 wires for bipolar connection | 54.50 | Double shaft with encoder fixing holes provision | 450 | IP30 |
 | MT24HE26028M403 | NEMA 24 - 60 mm square | 2070.00 | 1.80 | 5 | 280.00 | 4 wires for bipolar connection | 65.50 | Single shaft | 560 | IP30 |
 | MT24HE35030M801 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 300.00 | 8 wires for bipolar parallel or bipolar series connection | 85.50 | Single shaft | 810 | IP30 |
 | MT24HE35040M401 | NEMA 24 - 60 mm square | 2700.00 | 1.80 | 5 | 400.00 | 4 wires for bipolar connection | 85.50 | Single shaft | 922 | IP40 |
 | MT24HE35042M401 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 85.50 | Single shaft | 810 | IP30 |
 | MT24HE35042B401 | NEMA 24 - 60 mm square | 3000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 85.50 | Double shaft with encoder fixing holes provision | 810 | IP30 |
 | MT34HE26060M4K1 | NEMA 34 - 86 mm square | 3600.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 67.50 | Single shaft | 1100 | IP30 |
 | MT34HE26060M4K2 | NEMA 34 - 86 mm square | 3600.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 67.50 | Single shaft | 950 | IP30 |
 | MT23HE31042B4G2 | NEMA 23 - 56 mm square | 2000.00 | 1.80 | 5 | 420.00 | 4 wires for bipolar connection | 77.30 | Double shaft | 480 | IP30 |
 | MT34HE47060M4LC | NEMA 34 - 86 mm square | 8500.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 118.50 | Single shaft | 3800 | IP65 |
 | MT34HE47060B4LC | NEMA 34 - 86 mm square | 8500.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 118.50 | Single shaft | 2500 | IP65 |
 | MT34HE47120M4LC | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 1200.00 | 4 wires for bipolar connection | 118.50 | Single shaft | 2500 | IP65 |
 | MT34HE31060M4K2 | NEMA 34 - 86 mm square | 5360.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 79.30 | Single shaft | 1878 | IP40 |
 | MT34HE38040M4VK | NEMA 34 - 86 mm square | 7000.00 | 1.80 | 5 | 400.00 | 4 wires for bipolar connection | 96.50 | Single shaft | 2700 | IP43 |
 | MT34HE38060M4K1 | NEMA 34 - 86 mm square | 7000.00 | 1.80 | 5 | 600.00 | 4 wires for bipolar connection | 96.50 | Single shaft | 1850 | IP30 |
 | MT34HE47060M8K | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 118.00 | Single shaft | 3800 | IP40 |
 | MT34HE47060B8K | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 118.50 | Double shaft with encoder fixing holes provision | 3785 | IP30 |
 | MT34HE47090M401 | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 900.00 | 4 wires for bipolar connection | 118.50 | Single shaft | 2500 | IP30 |
 | MT34HE47090M8K | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 900.00 | 8 wires for bipolar parallel or bipolar series connection | 118.50 | Single shaft | 2500 | IP30 |
 | MT34HE47100M4R1 | NEMA 34 - 86 mm round | 10000.00 | 1.80 | 5 | 1000.00 | 4 wires for bipolar connection | 119.30 | Single shaft | 3700 | IP40 |
 | MT34HE47120M4K | NEMA 34 - 86 mm square | 11800.00 | 1.80 | 5 | 1200.00 | 4 wires for bipolar connection | 118.50 | Single shaft | 2500 | IP30 |
 | MT34HE50040M4VK | NEMA 34 - 86 mm square | 10000.00 | 1.80 | 5 | 400.00 | 4 wires for bipolar connection | 125.50 | Single shaft | 4000 | IP20 |
 | MT34HE62060M8K | NEMA 34 - 86 mm square | 12200.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 158.50 | Single shaft | 4800 | IP30 |
 | MT34HE62060B8K | NEMA 34 - 86 mm square | 12200.00 | 1.80 | 5 | 600.00 | 8 wires for bipolar parallel or bipolar series connection | 158.50 | Double shaft with encoder fixing holes provision | 4800 | IP30 |
 | MT42HE39075M8K | NEMA 42 - 110 mm square | 12000.00 | 1.80 | 5 | 750.00 | 8 wires for bipolar parallel or bipolar series connection | 99.00 | Single shaft | 5600 | IP40 |
 | MT42HE59110M8K | NEMA 42 - 110 mm square | 22000.00 | 1.80 | 5 | 1100.00 | 8 wires for bipolar parallel or bipolar series connection | 149.00 | Single shaft | 10900 | IP30 |
